Fan Coil Hoses
Fan coil hose assemblies provides reducing the transmission of noise and vibration that occur in fan-coil systems. In addition, its flexibility allows for ease of installation and small movements caused by piping expansion. They are suitable for cold water and hot water systems. There are insulated and non-insulated fan coil hose types.
Fan coil hoses do not require maintenance for a long time, they have a long service life. All raw materials used in our facility are recyclable.
Specifications
| Connection Diameter (inch) | 1/2″ – 2″ |
|---|---|
| Hose Diameter | DN12 – DN40 |
| Connection Type | Raccord – Nipple / Raccord – Raccord / Nipple- Nipple |
| Length | 200mm – 2000mm |
| Hose Material | Stainless Steel AISI 316L / AISI 304L (Optional) |
| Braiding Material | Stainless Steel AISI 304 |
| Fittings Material | Carbon Steel / Stainless Steel / Brass (Optional) |
| Ring Material | Stainless Steel AISI 304 |
| Insulation Material | Elastomeric Rubber |
- Alternative products and special requirements available upon request.
